224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯发电站用汽车发因素然油经济发展性好: 先进典型的然油调控体系，独立拥有的STC、ESTC 级别划分调控体系，特殊的定制的发动机活塞顶上燃燒室，高压低压发射然油，更加多方面做雾化，燃燒更加多方面。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯发电厂用发起机瞬态能力高品质: 精致的发起机纵向开发，积极配合康明斯多样的EFC操控系统，操控精准更高，没有响应时候快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯并网发电用起心理升功效高: 纵向设计构思紧身.造型布局合理有效，正常运行稳定。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷仪器 QSNT. QSK19. QSK38. QSK50能够满足我国非道路交通第一价段及南美Tier2. Tier 3的排放法律规范追求。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零零备件必须得要性好， 起思想运作及维修检修检修生活便利，成本费低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

额定功率的范围 Power Range   224-310KW结构类型 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L看上去寸尺 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净质 Dry Weight   940kg

224-310KW康明斯发电厂用打着机的性能：质量分数小， 压解比低， 排水槽水汽蒸汽加热，利于发动，联通车载一体机电压的优先选择。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

热车机款式	通常用工作功率(kW)Prime Power	紧急电功率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
